Jet/ Spray Nozzle 3 position, with Adapter, SOLAS/MED, Set

Name: Jet/ Spray Nozzle 3 position, with Adapter, SOLAS/MED, Set
Brand: Firespect Marine Safety Service
Availability: InStock

Storz, Nakajima adapter types are made of brass or aluminium.

Barcelona type adapter is made of aluminium.

UNI type adapter is made of brass.

For quotations or more information, please contact us by email at: 4service@firespect.se

Jet/ Spray Nozzle 3 position, ⌀12mm, w/ Male Inlet BSP 2″, SOLAS/MED

Jet/ Spray Nozzle 3 position, ⌀16mm, w/ Male Inlet BSP 2″, SOLAS/MED

Jet/ Spray Nozzle 3 position, ⌀19mm, w/ Male Inlet BSP 2″, SOLAS/MED

Diameter 12mm	Nominal pressure: 16 bar Working pressure: 6 bar Flow rate at straight jet: 236 l/min Flow rate at wide spray jet: 583 l/min Angle of a wide spray jet: 114° Effective throw: 28.5 m
Diameter 16mm	Nominal pressure: 16 bar Working pressure: 6 bar Flow rate at straight jet: 336 l/min Flow rate at wide spray jet: 590 l/min Angle of a wide spray jet: 115° Effective throw: 31 m
Diameter 19mm	Nominal pressure: 16 bar Working pressure: 6 bar Flow rate at straight jet: 382 l/min Flow rate at wide spray jet: 581 l/min Angle of a wide spray jet: 116° Effective throw: 2 m
